TERA 10-HE LOW INDASH NO KEYS

TERA 10 displays are among the most advanced for the off highway market.

Robust hardware, touch screen configuration and high computing power allow the development of intuitive and functional interface solutions.

The distinctive features of these products are: built-in installation; graphic fluidity; easy user interaction; maximum visibility; advanced connectivity; tablet-style look which, combined with specific project standards, make them particularly suitable for agricultural, industrial and road vehicles.

Technical specifications:

-Power supply: 8-32V

-Operating temperature: - 30°C ÷ +70°C

-Grade: IP65

-CPU: NXP i.MX6 Dual Core ARM Cortex-A9, 32 bit

-Frequency: 800MHz

-Internal memory: 8GB flash

-RAM: 1GB

-Display: TFT 10.1”, 1280 x 800 pixels, 850 cd/m², contrast ratio 800:1

-High readability in the sun

-RTC

-Internal temperature sensor

-Internal accelerometer/gyroscope

-Solo Touchscreen

-CANBUS port: 2

-Porte USB: 1 HOST external (BUTTONS VERSION); 2 HOST on connector; 1 OTG Device on connector
